  • YG-1 Z6185 No.4-48.00TPI Roll Form Bottoming 1.5P-2.0P HSSE-V3 Uncoated
Picture of YG-1 Z6185 No.4-48.00TPI Roll Form Bottoming 1.5P-2.0P HSSE-V3 Uncoated

YG-1 Z6185 No.4-48.00TPI Roll Form Bottoming 1.5P-2.0P HSSE-V3 Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-Z6185
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Vanadium: increases wear resistance of finishing tools. • Cobalt: enables increased hardening temperatures and improves heat resistance. All types of HSS contain significant amounts of carbon, which reacts with the refractory metals to form hard carbides, which increase wear resistance and hot hardness.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Shipping State Illinois
Application Roll Form Tapping, Bottom Tapping, Tapping, Blind Hole Tapping
Performance Rating General Performance
Package Size 1
Dimensional Specifications
Tap Square 0.1100
Length Type Standard
Tap Type Bottoming
Thread Pitch 48.00TPI
Machine Side Connection Type Tap Collet
Tap Chamfer 1.5P-2.0P
Thread Limit H5/GH5
Thread Type NF/UNF/UNEF
Dimension Standard ANSI/ANSI
Overall Len 1.8750 47.63MM
Thread Size No.4
Shank/Pilot Dia 0.1410 3.58MM
Cut Rating <30HRC Steel, Aluminum, Brass, Copper, Stainless Steel, Titanium
Tap Style Roll Form
Drill Range 0.1012 2.57MM - 0.1039 2.64MM
Tool Material Steel
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat HSSE-V3
Industry-Specific Applications
Job Shop Yes
