  • YG-1 Z6163 No.4-40.00TPI Roll Form Bottoming 1.5P-2.0P HSSE-V3 Uncoated
Picture of YG-1 Z6163 No.4-40.00TPI Roll Form Bottoming 1.5P-2.0P HSSE-V3 Uncoated

YG-1 Z6163 No.4-40.00TPI Roll Form Bottoming 1.5P-2.0P HSSE-V3 Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-Z6163
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Vanadium: increases wear resistance of finishing tools. • Cobalt: enables increased hardening temperatures and improves heat resistance. All types of HSS contain significant amounts of carbon, which reacts with the refractory metals to form hard carbides, which increase wear resistance and hot hardness.

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Shipping State Illinois
Made In USA No
Application Roll Form Tapping, Blind Hole Tapping, Bottom Tapping, Tapping
Performance Rating General Performance
Dimensional Specifications
Cut Rating <30HRC Steel, Aluminum, Brass, Copper, Stainless Steel, Titanium
Tap Chamfer 1.5P-2.0P
Tool Material Steel
Tap Square 0.1100
Thread Size No.4
Shank/Pilot Dia 0.1410 3.58MM
Thread Type NC/UNC
Thread Limit H3/GH3
Drill Range 0.0992 2.52MM - 0.1024 2.60MM
Length Type Standard
Tap Style Roll Form
Tap Type Bottoming
Thread Pitch 40.00TPI
Dimension Standard ANSI/ANSI
Overall Len 1.8750 47.63MM
Machine Side Connection Type Tap Collet
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat HSSE-V3
Industry-Specific Applications
Job Shop Yes
