Picture of WIDIA/KENNAMETAL E08KSCLCL065 80.0° Insert Boring Bar 0.315

WIDIA/KENNAMETAL E08KSCLCL065 80.0° Insert Boring Bar 0.315

ANSI: E08KSCLCL065

ISO: E08K-SCLCL065

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2031020
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Details

WIDIA LR SERIES BORING BAR

Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Made In USA No
Insert Type Positive
Application Int.Turning
Package Size 1
Insert/Tool Tool
Shipping State Pennsylvania
Dimensional Specifications
Insert Size Ic 06 "21"
Machine Side Connection Type Boring Bar
Lead Angle 95°
Tool Material Carbide
Machine Side Connection Size 0.3150 8.00MM
Overall Len 4.9213 125.00MM
Flutes/Inserts 1
Min Bore 0.3937
Shank/Pilot Dia 0.3150 8.00MM
Cutting & Machining Properties
Coolant Thru Yes
Hand R/L Left
Inter/Extern Internal
Insert Style CC
Insert Shape/Cutter Pocket Shape 80.0°
