Picture of WIDIA/KENNAMETAL CCPI31265R Carbide 45.0° Insert Boring Bar 0.312

WIDIA/KENNAMETAL CCPI31265R Carbide 45.0° Insert Boring Bar 0.312

ANSI: CCPI31265R

ISO: CCPI31265R

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2831762
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Features And Benefits

High desity carbided used to dampen vibration. Great for long reach boring.

Details

CARBIDE SHANK PROFILING BAR

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Shipping State Pennsylvania
Package Size 1
Insert Application General Purpose
Made In USA No
Insert Type Positive
Application Int.Turning
Dimensional Specifications
Flutes/Inserts 1
Tool Material Carbide
Machine Side Connection Type Boring Bar
Machine Side Connection Size 0.3125 7.94MM
Min Bore 0.4230
Lead Angle 95°
Insert Size Ic 05 "1.2"
Shank/Pilot Dia 0.3125 7.94MM - 5/16
Overall Len 6.0000 152.40MM
Cutting & Machining Properties
Insert Style GP
Insert Shape/Cutter Pocket Shape 45.0°
Hand R/L Right
Inter/Extern Internal
Coolant Thru Yes
