Picture of WIDIA/KENNAMETAL CCBM41007R Carbide 80.0° Insert Boring Bar 0.156

WIDIA/KENNAMETAL CCBM41007R Carbide 80.0° Insert Boring Bar 0.156

ANSI: CCBM41007R

ISO: CCBM41007R

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2831832
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Features And Benefits

High desity carbided used to dampen vibration. Great for long reach boring.

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Int.Turning
Insert/Tool Tool
Package Size 1
Insert Application General Purpose
Shipping State Pennsylvania
Made In USA No
Dimensional Specifications
Tool Material Carbide
Insert Size Ic S4
Lead Angle 97°
Min Bore 0.1800
Machine Side Connection Type Boring Bar
Machine Side Connection Size 0.1563 3.97MM
Shank/Pilot Dia 0.1563 3.97MM - 5/32
Overall Len 3.9500 100.33MM
Flutes/Inserts 1
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 80.0°
Inter/Extern Internal
Insert Style CD
Coolant Thru Yes
Hand R/L Right
