Picture of WIDIA/KENNAMETAL A24UMDUNR4 55.0° Insert Boring Bar 1.500

WIDIA/KENNAMETAL A24UMDUNR4 55.0° Insert Boring Bar 1.500

ANSI: A24UMDUNR4

ISO: A24UMDUNR4

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2951412
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Details

WIDIA LW SERIES BAR

Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Pennsylvania
Package Size 1
Application Int.Turning
Insert/Tool Tool
Dimensional Specifications
Machine Side Connection Type Boring Bar
Machine Side Connection Size 1.5000 38.10MM
Clearance Angle 20.0°
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Lead Angle 93°
Tool Material Steel
Insert Size Ic 12 "43"
Overall Len 14.0000 355.60MM
Flutes/Inserts 1
Min Bore 2.0000
Cutting & Machining Properties
Cool Sply Type 1/4-18 NPT
Inter/Extern Internal
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Coolant Thru Yes
Hand R/L Right
