WIDIA/KENNAMETAL 5402182 M5-0.50MM Cut Spiral Flute Mod Bottom 2.5P-3.0P HSSE Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID5402182
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Shipping State Ohio
Application Cut Tapping, Mod Bottom Tapping, Tapping
Performance Rating High Performance
Made In USA No
Dimensional Specifications
Tool Material Steel
Drill Range 0.1764 4.48MM - 0.1815 4.61MM
Thread Pitch 0.50MM
Machine Side Connection Type Tap Collet
Tap Square 0.1060
Thread Size M5
Dimension Standard DIN/DIN
Shank/Pilot Dia 0.1370 3.48MM
Overall Len 2.7600 70.10MM
Flutes/Inserts 3
Thread Limit 6H
Tap Style Cut Spiral Flute
Tap Type Mod Bottom
Thread Type Metric
Cut Rating <40HRC Steel, Aluminum, Brass, Copper, Stainless Steel
Tap Chamfer 2.5P-3.0P
Flute Direction R - Right
Length Type Standard
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat HSSE
Industry-Specific Applications
Job Shop Yes
