Picture of ISCAR FF EW D1.5-2.5-CF4-09-C Milling Cutter 1.500 Diameter Clickfit 1.574 4.470 OAL 3 Flute

ISCAR FF EW D1.5-2.5-CF4-09-C Milling Cutter 1.500 Diameter Clickfit 1.574 4.470 OAL 3 Flute

ANSI: FF EW D1.5-2.5-CF4-09-C

ISO: FF EW D1.5-2.5-CF4-09-C

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3103480
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Face Milling, Copy Milling, Feed Milling, Ramp Milling, Slot Milling
Package Size 1
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Shipping State Texas
Dimensional Specifications
Insert Size Ic 9
Cut Dia Min 0.6800 17.27MM
Shank/Pilot Dia 1.5748 40.00MM
Machine Side Connection Type CLICK FIT
Tool Material Steel
Overall Len 4.4700 113.54MM
Depth Of Cut Max 0.8270
Cutter Dia 1.5000 38.10MM - 1-1/2
Cut Dia Max 1.5000 38.10MM - 1-1/2
Machine Side Connection Size 1.5748 40.00MM
Flutes/Inserts 3
Cutting & Machining Properties
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Trigon
Max Ramp Angle 5.00°
Coolant Thru Yes
Insert Style FF
Fasteners & Connectors
Insert Screw 7000216
