Picture of INGERSOLL ON5H-60R01 Milling Cutter 45.0° 6.000 Shell Arbor 1.5000 18 Flute 0.12 Max DOC 2.375 OAL

INGERSOLL ON5H-60R01 Milling Cutter 45.0° 6.000 Shell Arbor 1.5000 18 Flute 0.12 Max DOC 2.375 OAL

ANSI: ON5H-60R01

ISO: ON5H-60R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3030045
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing, Finishing
Insert Type Negative
Shipping State Illinois
Made In USA No
Insert/Tool Tool
Application Face Milling
Package Size 1
Dimensional Specifications
Cut Dia Max 6.3300 160.78MM
Insert Size Ic 5
Machine Side Connection Type Face Mill/Shell Mill
Tool Material Steel
Cutter Dia 6.0000 152.40MM
Depth Of Cut Max 0.1200
Cut Dia Min 6.0000 152.40MM
Overall Len 2.3750 60.33MM
Flutes/Inserts 18
Machine Side Connection Size 1.5000 38.10MM
Cutting & Machining Properties
Insert Style ON
Insert Shape/Cutter Pocket Shape Octagonal
Coolant Thru No
