  • AB ToolS APD11-100 Parallelogram 100.0°, Back Chamfer , Chamfer ing, End Mill Cylindrical 0.5000 Positive 1.3750 34.93MM - 1-3/8 Cutter Dia
Picture of AB ToolS APD11-100 Parallelogram 100.0°, Back Chamfer , Chamfer ing, End Mill Cylindrical 0.5000 Positive 1.3750 34.93MM - 1-3/8 Cutter Dia

AB ToolS APD11-100 Parallelogram 100.0°, Back Chamfer , Chamfer ing, End Mill Cylindrical 0.5000 Positive 1.3750 34.93MM - 1-3/8 Cutter Dia

ANSI: APD11-100

ISO: APD11-100

Need Assistance or Service? Please call 262-251-4020

Manufacturer: AB TOOLS
SKU: ABTAPD11-100
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Features And Benefits

All purpose chamfer mills

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Insert Application General Purpose
Application Back Chamfering, Chamfering
Package Size 1
Insert/Tool Tool
Made In USA Yes
Shipping State California
Dimensional Specifications
Dimension Description 1.375 x 0.500 x 0.210 x 2.500
Depth Of Cut Max 0.2550
Overall Len 2.5000 63.50MM
Tool Material Steel
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Insert Size Ic 11
Machine Side Connection Size 0.5000 12.70MM
Cutter Dia 1.3750 34.93MM - 1-3/8
Cut Dia Min 1.3750 34.93MM - 1-3/8
Flutes/Inserts 3
Machine Side Connection Type Cylindrical
Length Of Cut 0.2100 5.33MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Extractor T8
Insert Style AP
Fasteners & Connectors
Insert Screw 2.5MM-AP
